UI Module Overview

What is the PetnowUI module?

PetnowUI is a module that provides a ready-to-use camera UI for capturing pet biometric data. It handles all the complex camera setup, detection logic, image processing, and more, so developers can integrate professional biometric recognition into their app with just a few lines of code.

Core Values

• 🚀 Fast integration: No need to know the complex camera API
• 🎯 Real-time guidance: Guides users to the optimal way to capture
• 🎨 Customizable: Adjustable to match your app's design
• 📱 SwiftUI & UIKit support: Usable in any iOS app

Architecture

The PetnowUI module hides the complex state management and ML framework integration logic, exposing only a simple interface to developers.

Core Components

CameraView

A SwiftUI View that displays the camera preview and detection overlay.

Responsibilities:

• Render the camera preview
• Display the detection overlay
• Handle user interaction

Simple usage example:

// Basic usage
CameraView(controller: controller)

// Add a custom overlay
CameraView(controller: controller) {
    Text("Please center the nose")
        .foregroundColor(.white)
        .padding()
        .background(Color.black.opacity(0.7))
        .cornerRadius(8)
}

CameraController

A view model that is an ObservableObject and is injected into CameraView.

Session concepts

The capture process is managed with two kinds of sessions:

Capture Session

• Created by calling the createCaptureSession API on the server
• Pass the created captureSessionId to initializeCamera() to start capturing
• A single Capture Session can contain multiple Detection Sessions
• Used in the Petify Console to track the entire capture process and analyze metrics

Detection Session

• The session from the moment actual detection starts until detection completes or fails
• When the user re-captures, a new Detection Session starts

Note: A new Detection Session starts on re-capture. You can track each session individually in the Petify Console.

State Management

DetectionStatus

Represents the detection result state of the camera frame. It updates roughly every second.

public enum DetectionStatus {
    case noObject                            // No target detected
    case processing                          // Detection in progress
    case detected                            // Detection succeeded
    case failed(reason: DetectionFailureReason)  // Failed (includes reason)
    case finished                            // Capture complete
}

CameraResult

The final capture result.

public enum CameraResult {
    case success(
        fingerprintImages: [URL],  // Fingerprint/nose-print images
        appearanceImages: [URL]    // Appearance images
    )
    case fail                      // Capture failed
}

Data Flow

Key point: When CameraController publishes state, your custom camera screen uses those state values together with CameraView to build the UI. When capture completes, CameraResult is delivered via the callback.

Data flow explanation

1. Real-time state updates

• CameraController publishes the following state with @Published:
  • detectionStatus: .noObject, .processing, .detected, .failed(reason:), .finished
  • currentDetectionProgress: 0 ~ 100 (Int, detection progress)
  • detectedObjectNormalizedRect: detected region (normalized coords), detectionResult: nose/face BoundingBox
  • isSwitchButtonEnabled, isInitialized
• The custom camera screen subscribes to these state values to update the UI.

2. Final result delivery

• When detection completes, CameraController saves the images and creates a CameraResult.
• CameraResult.success or CameraResult.fail is delivered through the callback.

Best Practices

1. ViewModel lifecycle management

// SwiftUI: use @StateObject
@StateObject private var viewModel = CameraController(...)

// Cleanup
.onDisappear {
    viewModel.finalizeCamera()
}

2. Error handling

do {
    try await viewModel.initializeCamera(...)
} catch PetnowUIError.invalidLicense(let error) {
    // Handle license error
} catch PetnowUIError.permissionDenied(let message) {
    // Handle permission error
} catch {
    // Handle other errors
}

3. State observation

// Actions based on a specific state
.onChange(of: viewModel.detectionStatus) { status in
    switch status {
    case .detected:
        playSuccessSound()
    case .failed(let reason):
        showErrorMessage(reason)
    default:
        break
    }
}

Next Steps

Once you understand the structure of the UI module, refer to the following documents:

• Basic Usage - Integrate CameraView
• Customization - Customize the overlay
• Sound Guide - Detailed guide on sound playback
