UI Module Overview

What is the Petnow UI Module?

The Petnow UI module is a module that provides a ready-to-use camera engine for capturing pet biometric data. It handles all the complex camera setup, detection logic, and image processing, so developers can integrate professional biometric recognition features into their apps with just a few lines of code.

Core Values

• 🚀 Fast integration: No need to understand the complex Camera2 API
• 🎯 Real-time guidance: Guides users on the optimal way to capture
• 🎨 Customizable: Adjustable to match your app's design
• 🧩 Flexible hosting: Integrate anywhere — View, Jetpack Compose, React Native, and more

Core Components

The UI module consists of a single engine (CameraController) and multiple hosting methods that place it on the screen.

CameraController (Engine)

The core component that manages the entire lifecycle of the camera/detection session. It is not involved in UI rendering; it only forwards state and events to the outside.

import io.petnow.ui.CameraController
import io.petnow.ui.config.LicenseInfo

val controller = CameraController(
    context,
    LicenseInfo(apiKey = "YOUR_API_KEY", isDebugMode = false),
    coroutineScope,
)

Responsibilities:

• Opening/closing the camera, starting/pausing/resuming the detection session
• Providing the detection state via the PetnowCameraDetectionListenerV2 callback and getState() (StateFlow)
• Delivering the final result (CameraResult) via a callback

Choosing a Hosting Method

Architecture

The Petnow UI module hides the complex state management and ML framework integration logic, providing developers with only a simple interface.

Session Concepts

The capture process is managed by two types of sessions:

Capture Session

• Created by calling the Petnow Server API (createCaptureSession) from your server
• The captureSessionId received from the server is passed to the client and supplied to initializeCamera()
• One Capture Session can contain multiple Detection Sessions

Detection Session

• A session from when actual detection starts until detection completes or fails
• When the user retakes (calls startDetection() again), a new Detection Session starts

How to Pass captureSessionId

Pass the captureSessionId (UUID) received from the server to initializeCamera().

import java.util.UUID

lifecycleScope.launch {
    // Obtain the captureSessionId from your server
    // (the server calls createCaptureSession of the Petnow Server API)
    val captureSessionId: UUID = yourServerApi.createCaptureSession(
        species = "DOG",
        purpose = "PET_PROFILE_REGISTRATION",
    )

    controller.initializeCamera(configuration, captureSessionId)
    controller.startDetection()
}

State Management

DetectionStatus

The representative detection status of the current frame, delivered via PetnowCameraDetectionListenerV2.onDetectionStatus. It is a sealed class, and Failed includes a specific cause (reason).

import io.petnow.ui.status.DetectionStatus
import io.petnow.ui.status.DetectionFailureReason

sealed class DetectionStatus {
    data object NoObject : DetectionStatus()     // No target detected
    data object Processing : DetectionStatus()    // Detection in progress
    data object Detected : DetectionStatus()      // Detection succeeded
    data object Finished : DetectionStatus()      // Capture complete
    data class Failed(val reason: DetectionFailureReason) : DetectionStatus()
}

For the full list of DetectionFailureReason values, see Basic Usage.

CameraResult

The final capture result.

import io.petnow.ui.CameraResult

sealed class CameraResult {
    data class Success(
        val fingerprintImageFiles: List<File>,  // For biometric recognition (dog = nose, cat = face)
        val appearanceImageFiles: List<File>    // Appearance (face) images
    ) : CameraResult()

    data object Fail : CameraResult()
}

Data Flow

Key point: Once you create a CameraController and register a PetnowCameraDetectionListenerV2, the controller handles all camera logic and delivers only the necessary events via callbacks.

Data Flow Description

1. Real-time status updates

• You receive the following events through PetnowCameraDetectionListenerV2:
  • onDetectionStatus(status): The detection status of the current frame (DetectionStatus)
  • onDetectionProgress(progress): Detection progress (0 ~ 100)
• If you need nose/face tracking boxes, use getState().currentDetectionResult (DetectionResult).

2. Final result delivery

• When detection completes, the controller saves the images and creates a CameraResult.
• The result is delivered via the onDetectionFinished(result) callback.
  • CameraResult.Success - Capture successful (includes the image file list)
  • CameraResult.Fail - Capture failed

Next Steps

Now that you understand the structure of the UI module, refer to the following documentation:

• Basic Usage - Integrating CameraView + CameraController
• Fully Custom UI - A 100% custom UI with your own SurfaceView
• Customization - Customizing the CameraView guide UI
• Sound Guide - Detailed sound playback guide
• Fragment Method (Legacy) - The existing PetnowCameraFragment integration method
